Shackles Bow BD
230271 SHACKLE BOW EYE BOLT GALV, JIS-BD 6MM SWL 0.15TON
IMPA:230271
MTML UOM:PCE
A weldless, drop forged, carbon steel shackle with an eye bolt which has metric coarse threads on the end. Please specify Ungalvanized (Black) shackle or Galvanized shackle is required. Galvanized. Size: Body dia: 6mm, Opening: 12mm, Screw Pin Thread: M 8, Clear Length: 32mm, Pin dia: 8mm, S.W.L: 0.15ton
230272 SHACKLE BOW EYE BOLT GALV, JIS-BD 8MM SWL 0.3TON
IMPA:230272
MTML UOM:PCE
A weldless, drop forged, carbon steel shackle with an eye bolt which has metric coarse threads on the end. Please specify Ungalvanized (Black) shackle or Galvanized shackle is required. Galvanized. Size: Body dia: 8mm, Opening: 16mm, Screw Pin Thread: M10, Clear Length: 40mm, Pin dia: 10mm, S.W.L: 0.3ton.
230273 SHACKLE BOW EYE BOLT GALV, JIS-BD 10MM SWL 0.5TON
IMPA:230273
MTML UOM:PCE
A weldless, drop forged, carbon steel shackle with an eye bolt which has metric coarse threads on the end. Please specify Ungalvanized (Black) shackle or Galvanized shackle is required. Galvanized. Size: Body dia: 10mm, Opening: 20mm, Screw Pin Thread: M12, Clear Length: 48mm, Pin dia: 12mm, S.W.L: 0.5ton.
230274 SHACKLE BOW EYE BOLT UNGALV, JIS-BD 12MM SWL 0.7TON
IMPA:230274
MTML UOM:PCE
A weldless, drop forged, carbon steel shackle with an eye bolt which has metric coarse threads on the end. Please specify Ungalvanized (Black) shackle or Galvanized shackle is required. Ungalvanized. Size: Body dia: 12mm, Opening: 24mm, Screw Pin Thread: M14, Clear Length: 55mm, Pin dia: 15mm, S.W.L: 0.7ton.
230275 SHACKLE BOW EYE BOLT UNGALV, JIS-BD 14MM SWL 0.9TON
IMPA:230275
MTML UOM:PCE
A weldless, drop forged, carbon steel shackle with an eye bolt which has metric coarse threads on the end. Please specify Ungalvanized (Black) shackle or Galvanized shackle is required. Ungalvanized. Size: Body dia: 14mm, Opening: 28mm, Screw Pin Thread: M16, Clear Length: 63mm, Pin dia: 17mm, S.W.L: 0.9ton.
230276 SHACKLE BOW EYE BOLT UNGALV, JIS-BD 16MM SWL 1.2TON
IMPA:230276
MTML UOM:PCE
A weldless, drop forged, carbon steel shackle with an eye bolt which has metric coarse threads on the end. Please specify Ungalvanized (Black) shackle or Galvanized shackle is required. Ungalvanized. Size: Body dia: 16mm, Opening: 32mm, Screw Pin Thread: M20, Clear Length: 70mm, Pin dia: 20mm, S.W.L: 1.2ton.
230277 SHACKLE BOW EYE BOLT UNGALV, JIS-BD 18MM SWL 1.3TON
IMPA:230277
MTML UOM:PCE
A weldless, drop forged, carbon steel shackle with an eye bolt which has metric coarse threads on the end. Please specify Ungalvanized (Black) shackle or Galvanized shackle is required. Ungalvanized. Size: Body dia: 18mm, Opening: 36mm, Screw Pin Thread: M20, Clear Length: 89mm, Pin dia: 21mm, S.W.L: 1.3ton.
230278 SHACKLE BOW EYE BOLT UNGALV, JIS-BD 20MM SWL 1.8TON
IMPA:230278
MTML UOM:PCE
A weldless, drop forged, carbon steel shackle with an eye bolt which has metric coarse threads on the end. Please specify Ungalvanized (Black) shackle or Galvanized shackle is required. Ungalvanized. Size: Body dia: 20mm, Opening: 40mm, Screw Pin Thread: M24, Clear Length: 100mm, Pin dia: 24mm, S.W.L: 1.8ton
231471 SHACKLE BOW EYE BOLT UNGALV, JIS-BD 6MM SWL 0.15TON
IMPA:231471
MTML UOM:PCE
A weldless, drop forged, carbon steel shackle with an eye bolt which has metric coarse threads on the end. Please specify Ungalvanized (Black) shackle or Galvanized shackle is required. Ungalvanized. Size: Body dia: 6mm, Opening: 12mm, Screw Pin Thread: M 8, Clear Length: 32mm, Pin dia: 8mm, S.W.L: 0.15ton
231472 SHACKLE BOW EYE BOLT UNGALV, JIS-BD 8MM SWL 0.3TON
IMPA:231472
MTML UOM:PCE
A weldless, drop forged, carbon steel shackle with an eye bolt which has metric coarse threads on the end. Please specify Ungalvanized (Black) shackle or Galvanized shackle is required. Ungalvanized. Size: Body dia: 8mm, Opening: 16mm, Screw Pin Thread: M10, Clear Length: 40mm, Pin dia: 10mm, S.W.L: 0.3ton.
231473 SHACKLE BOW EYE BOLT UNGALV, JIS-BD 10MM SWL 0.5TON
IMPA:231473
MTML UOM:PCE
A weldless, drop forged, carbon steel shackle with an eye bolt which has metric coarse threads on the end. Please specify Ungalvanized (Black) shackle or Galvanized shackle is required. Ungalvanized. Size: Body dia: 10mm, Opening: 20mm, Screw Pin Thread: M12, Clear Length: 48mm, Pin dia: 12mm, S.W.L: 0.5ton.
231474 SHACKLE BOW EYE BOLT GALV, JIS-BD 12MM SWL 0.7TON
IMPA:231474
MTML UOM:PCE
A weldless, drop forged, carbon steel shackle with an eye bolt which has metric coarse threads on the end. Please specify Ungalvanized (Black) shackle or Galvanized shackle is required. Galvanized. Size: Body dia: 12mm, Opening: 24mm, Screw Pin Thread: M14, Clear Length: 55mm, Pin dia: 15mm, S.W.L: 0.7ton.
231475 SHACKLE BOW EYE BOLT GALV, JIS-BD 14MM SWL 0.9TON
IMPA:231475
MTML UOM:PCE
A weldless, drop forged, carbon steel shackle with an eye bolt which has metric coarse threads on the end. Please specify Ungalvanized (Black) shackle or Galvanized shackle is required. Galvanized. Size: Body dia: 14mm, Opening: 28mm, Screw Pin Thread: M16, Clear Length: 63mm, Pin dia: 17mm, S.W.L: 0.9ton.
231476 SHACKLE BOW EYE BOLT GALV, JIS-BD 16MM SWL 1.2TON
IMPA:231476
MTML UOM:PCE
A weldless, drop forged, carbon steel shackle with an eye bolt which has metric coarse threads on the end. Please specify Ungalvanized (Black) shackle or Galvanized shackle is required. Galvanized. Size: Body dia: 16mm, Opening: 32mm, Screw Pin Thread: M20, Clear Length: 70mm, Pin dia: 20mm, S.W.L: 1.2ton.
231477 SHACKLE BOW EYE BOLT GALV, JIS-BD 18MM SWL 1.3TON
IMPA:231477
MTML UOM:PCE
A weldless, drop forged, carbon steel shackle with an eye bolt which has metric coarse threads on the end. Please specify Ungalvanized (Black) shackle or Galvanized shackle is required. Galvanized. Size: Body dia: 18mm, Opening: 36mm, Screw Pin Thread: M20, Clear Length: 89mm, Pin dia: 21mm, S.W.L: 1.3ton.
231478 SHACKLE BOW EYE BOLT GALV, JIS-BD 20MM SWL 1.8TON
IMPA:231478
MTML UOM:PCE
A weldless, drop forged, carbon steel shackle with an eye bolt which has metric coarse threads on the end. Please specify Ungalvanized (Black) shackle or Galvanized shackle is required. Galvanized. Size: Body dia: 20mm, Opening: 40mm, Screw Pin Thread: M24, Clear Length: 100mm, Pin dia: 24mm, S.W.L: 1.8ton
